Data transmission |
|
| Jumbo Frames support |
|
| MAC address table | 16000 entries |
| Number of queues | 8 |
| Number of VLANs | 4000 |
| Switching capacity | 104 Gbit/s |
| Throughput | 77.4 Mpps |
|
Design |
|
| Colour of product | Black |
| Form Factor | 1U |
| Rack mounting |
|
| Ventilation fan(s) | 3 |
|
Management features |
|
| Multicast support |
|
| Quality of Service (QoS) support |
|
| Switch layer | L2+ |
| Switch type | Managed |
| Web-based management |
|
|
Networking |
|
| 10G support |
|
| Auto MDI/MDI-X |
|
| Broadcast storm control |
|
| Flow control support |
|
| IGMP snooping |
|
| Link aggregation |
|
| Networking standards | IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| Port mirroring |
|
| Spanning tree protocol |
|
| VLAN support |
|
|
Performance |
|
| Firmware upgradeable |
|
| Stackable | - |
|
Ports & interfaces |
|
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
| Gigabit Ethernet (copper) ports quantity | 48 |
| SFP ports quantity | 4 |
| SFP+ ports quantity | 0 |
|
Power |
|
| AC input frequency | 50/60 Hz |
| AC input voltage | 100-240 V |
| Energy Star certified | - |
| Power consumption (typical) | 470.4 W |
|
Power Over Ethernet (PoE) |
|
| Power over Ethernet (PoE) Support |
|
| Power over Ethernet plus (PoE+) ports quantity | 48 |
| Total Power over Ethernet (PoE) budget | 384 W |
|
Protocols |
|
| Management protocols | SNMP v1/v2c/v3, RMON, TFTP |
|
Security |
|
| Access Control List (ACL) |
|
| Security algorithms | 802.1x RADIUS,SSH,SSL/TLS |
| SSH/SSL support |
|
|
Operational conditions |
|
| Operating relative humidity (H-H) | 10 - 90 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
|
Packaging data |
|
| Cables included | AC |
| Quick Start Guide |
|
|
System Requirements |
|
| Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux. |
|
Weight & dimensions |
|
| Depth | 330 mm |
| Height | 44 mm |
| Width | 440 mm |
