08719844418PRODUCT FEATURES:¤¤Built-in static bypass, Internal bypass¤¤Less than 5% for full load¤¤Maintenance-free sealed lead-acid battery with suspended electrolyte¤¤Multi-function LCD status and control console¤¤Audible and visible alarms¤¤Full time multi-pole noise filtering¤¤0.3% IEEE surge let-through¤¤Zero clamping response time
Battery
|
|
| Battery recharge time | 2.5 h |
| Battery Technology | Sealed Lead Acid (VRLA) |
| Replacement battery cartridge | RBC44 |
| Typical backup time at full load | 4.9 min |
| Typical backup time at half load | 15.3 min |
Design
|
|
| Colour of product | Black |
Performance
|
|
| Audible alarm(s) | |
| Noise level | 59 dB |
Ports & interfaces
|
|
| Ethernet LAN (RJ-45) ports | 1 |
| Number of output IEC jumpers | 2 |
| Serial ports quantity | 1 |
Power
|
|
| Emergency Power Off (EPO) | |
| Maximum current | 105 A |
| Output power | 16000 W |
| Output power capacity | 20000 VA |
| Power supply input frequency | 40/70 Hz |
Certificates
|
|
| Certification | EN/IEC 62040-2,EN/IEC 62040-1-1,VDE |
Operational conditions
|
|
| Non-operating altitude | 0 - 15000 m |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -15 - 45 °C |
Other features
|
|
| Dimensions (WxDxH) | 432 x 773 x 533 mm |
| Input connection type | (1PH+N+G), (3PH + N + G) |
| Interface | DB-9 RS-232, RJ-45 10/100 Base-T, Smart-Slot |
| Networking features | 10/100 BASE-T |
| Nominal input voltage | 230 V |
| Nominal output voltage | 230 V |
| Output connections |
(1) Hard Wire 3-wire (H N + G), (1) Hard Wire 5-wire (3PH + N + G), (8) IEC 320 C19 |
| Output voltage note | 230/240 |
| Package dimensions (WxDxH) | 610 x 1003 x 990 mm |
| Quantity per pallet | 1 pc(s) |
Weight & dimensions
|
|
| Package weight | 314270 g |
| Weight | 247730 g |
